AFV-PMD2AM-W

2MP Mini Dome Camera

Key Features

  • Metal Housing
  • Up to 1920×1080@30fps
  • S+265/H.265/H.264
  • Min. illumination Color: 0.002Lux@F1.6
  • Smart IR, IR Range: 30m
  • Built-in Mic , SD Card Solt
  • Audio I/O 1/1,Alarm I/O 1/1
  • Support tripwire,perimeter
  • Human/Vehicle Classification
  • Built-in Mic, SD Card Solt
  • Operating Conditions -40°~65°, 0~95% RH
  • DC12V,POE
  • IP67,IK10
Category:
Inquire Now

Specification

Image Sensor 1/2.8″
Signal System PAL/NTSC
Min. Illumination Color:0.002Lux@(F1.6, AGC ON),B/W:0Lux with IR
Shutter Time 1s to 1/100,000s
Day&Night Dual IR Cut Filter with Auto Switch
WDR 120dB/td>
Angle Adjustment -30°~30°,0~75°,0~360°
Lens Type Fixed
Focal Length 2.8(4)mm
Lens Mount M12
Aperture Range F1.6
Field of View Horizontal field of view: 101.7°(2.8mm)/85.2° (4mm)
Vertical field of view: 57.4°(2.8mm)/44.9° (4mm)
Diagonal field of view: 114.2°(2.8mm)/96.1° (4mm)
Max. Resolution 1920×1080
Main Stream PAL:25fps(1920×1080, 1280×720,640×480, 704×576)
NTSC:30fps(1920×1080, 1280×720,640×480, 704×480)
Sub Stream PAL:25fps(704×576, 704×288,352×288, 640×360)
NTSC:30fps(704×480, 704×240,352×240, 640×360)
Third Steam PAL:25fps(704×576, 704×288,352×288)
NTSC:30fps(704×480, 704×240,352×240)
Image Setting Saturation,brightness, contrast,sharpness, adjustableby client software or web browser
Image Enhancement BLC/3D DNR/HLC/AGC
ROI Yes,8 regions
OSD 16*16/32*32/48*48/ 64*64,adaptable size, Letters Such as Week, Date,Time,Total 5 Regions
Picture Overlay Yes
Privacy Mask Yes,4 regions
Defog Yes
Video Compression S+ 265/H.264B/H.264M/ H.264H/Motion JPEG
Video Bit Rate 32kbps~8Mbps
Audio Compression G.711A/G.711U/ ADPCM_D/AAC_LC
Audio Sampling Rate 8kHz/32kHz/48kHz
Alarm Trigger Voltage Alarm,Disk Full, Disk R/W Error,IP Address Conflict,MAC Address Conflict,
FTP Server Exception ,Event Input, Event Output,Motion Detection,Mask Alarm
Video Analytics Human/Vehicle Classification,Tripwire, Perimeter
ANR Yes
Protocols HTTP,HTTPS,TCP/IP,UDP, UPnP,ICMP,IGMP,SNMP, DHCP,DNS,DDNS,Easy DDNS,NTP,SSL,802.1X,
QoS,IPv4,IPv6,PPPOE, SSH,Unicast,Multicast, RTCP,ARP
System Compatibility onvif Profile S/T/G/CGI; MILSTONE, RTMP
Remote Connection 2
Client Easy7,EasyLive Plus
Web IE,Firefox, Edge, Safari, Chrome
Communication Interface 1 RJ45 10M/ 100M self adaptive Ethernet port
Audio I/O 1/1
Alarm I/O 1/1
Built-In Speaker N/A
Built-In Mic Yes
Reset Button Yes
On-board storage Built-in MicroSD card slot, up to 512GB
Web Client Language 18 languages English, Russian,Spanish, Korean, Italian,Turkish, Simple Chinese,Traditional Chinese,
Thai,French, Polish,Dutch,Hebrew, Arabic,
Vietnamese, German,Ukrainian, Portuguese
Operating Conditions -40C~65C,0~95%RH
Power Supply POE(802.3af)
Power Consumption ≤7W
Protection IP67, IK10
Boundary Dimensions 110mmx110mmx60mm
Package Dimensions 138mmx138mmx110mm
GrossWeight 0.5kg
NetWeight 0.4kg
IR LEDs 2
IR Distance Up to 30m
Wavelength 850nm
White LEDs N/A
